DSR AVR Automatic Voltage Regulator A6762 Generator
Features:
1. Easy to operate with multi-function control system
2. Adopt fully digital control, it can achieve computer links.
3. This voltage regulator can achieve fast opening and fast closing
4. Monitor real-time performance: voltage, frequency
5. This voltage regulator adopts PLC connection
Specification:
Condition: 100% Brand new
Variable Voltage Power Supply: 40-270VAC
Frequency Range: 15 Hz-72 Hz
Voltage Regulation Accuracy: ± 1%
Maximum Continuous Output Current: 5A DC
Ambient Temperature: -25℃ - +70℃
Adjust the True RMS or Average Measured Value: (70- 280V DC)
Transient Power Drop and Overvoltage within ±15%
Voltage recovery time is less than 300 milliseconds within ±3% of the set value
Transient overvoltage during start-up is less than 5% of nominal voltage
Induction, Single Phase
